R8 Meta
Listen and believe
Don’t just take our word for it. The best way to really appreciate the power of the R Series is to listen to it for yourself. Book a demo and experience the way the R Series immerses you in sound.
DESIGN
Two-way closed box
DRIVE UNITS
Uni-Q Driver Array:
HF: 25 mm (1 in.) vented aluminium dome with MAT
MF/ LF: 130 mm (5.25 in.) aluminium cone
CROSSOVER FREQUENCY
2.6 kHz
FREQUENCY RANGE (-6dB)
88 Hz – 19.5 kHz
TYPICAL IN-ROOM BASS RESPONSE (-6dB)
–
FREQUENCY RESPONSE (±3dB)
97 Hz – 17.5 kHz
HARMONIC DISTORTION (90dB, 1m)
<1% 220 Hz and above
<0.5% 320 Hz - 20 kHz
MAXIMUM OUTPUT
106 dB
AMPLIFIER REQUIREMENTS
25 - 150W
NOMINAL IMPEDANCE
4 Ω (min. 3.2 Ω)
SENSITIVITY (2.83V/1m)
85 dB
WEIGHT *
4.5 kg (9.9 lbs.)
DIMENSION (H x W x D) WITH TERMINAL *
174 x 175 x 259 mm (6.9 x 6.9 x 10.2 in.)
FINISHES
Black Gloss / White Gloss / Walnut
